Water dispenser detection system
The system detects and outputs the rated power supply to the tested outdoor and indoor standard units. Depending on the model, the program controls the operation of the outdoor unit by outputting signals to the compressor, four-way valve, fan, etc., through control points.
Detailed description
Conditions of Use
Operating Time: 24 hours a day
Operating Ambient Temperature: -10—45℃, Humidity ≤95%
Operating Power Supply: 220/380V, 50HZ. Voltage fluctuation range ±10%.
Relative Humidity: 45%~95%; Compressed Air: 0.4-0.55MPA
Applicable Products
Products | Projects | Regardless of Season | Remarks |
Heat Pump Hot and Cold Water Machine | Ambient Temperature | 25±5 degrees Celsius |
|
Inlet Water Temperature | 15-35 degrees Celsius |
|
Water System Parameters
Projects | Water Flow Rate | Waterway Component Water Resistance Temperature | Water Pressure | Remarks |
Parameters | 0.5-6m³/h | >85 degrees Celsius | 0.2-0.6MPa | Water flow rate and water temperature can be adjusted and controlled |
Main Function Introduction
The system detects and outputs the rated power supply to the tested outdoor unit and indoor standard unit. Depending on the model, the program controls the operation of the outdoor unit by outputting signals such as the compressor, four-way valve, and fan through the control point. The system detects parameters such as current, power, temperature, and pressure to determine whether the tested outdoor unit is qualified. Test unit corresponding protocol information: The communication protocol for variable frequency models is provided by the client.
